  MAIN PARAMETERS

HX-800KIIIHX-1360KIIIHX-1780KIII
LEDBacklight LCD
Maximum paper width800mm1360mm1780mm
Real time range720mm×limitless1250mm×limitless1650mm×limitless
Cutting pressure20-950g
Cutting speed25mm/s-800mm/s
Mechanical resolution0.0254mm/step
InterfaceUSB2.0/RS232
Support softwareArtcut/Cut Master
BracketWith
JREWindows XP/vista/7
MAIN APPLICATION

  Support the forward and reverse paper feeding, emergency stop, any set of origin, with maximum speed of 800mm/s.
  Low power design of the circuit, no need of cooling fan, to ensure the reliable long-time operation.
  Perfect output, absolutely no sawtooth in high speed.
  USB2.0/RS232 Double joint support, soft curve line connection, more solid and durable.
  Using the switching power supply, is not affected by the voltage fluctuation.
  Memory storage of cutter speed, blade pressure; reduction with double light panels.
  Using the most advanced subdivision, embedding type head, the most advanced control chip, no noisein cutting.
  Direct push head, knife pressure can reach 800g, strong pressure can cut any reflective film.
  English backlit LCD displaypanel, clear operation.
