  MAIN PARAMETERS
TypeHX-720NHX-800NHX-960NHX-1120NHX-1360N
Maximum paper feed width720mm(28.4")800mm(31.5")960mm(37.8")1120mm(44.1")1360mm(53.6")
Real cutting range630mm(24.8")*limitless length720mm(27.6")*limitless length860mm(33.9")*limitless length1010mm(39.8")*limitless length1250mm(49.2")*limitless length
Cutting speed25mm/s-500mm/s(0.98"/s-19.7"/s)
Cutter pressure25-500g Grade 16-32
English LCD With
MechanicalResolution0.0254 mm/step(0.001"/step)
Blade  TypeSwivel Standard blade (Compatible with Roland blade)
Interfaces USB 2.0 and RS232 serial interface
Commands/Language HP-GL / DMPL compatible
BracketWith
MAIN APPLICATION

  Forward direction and reverse direction paper feed

  Emergency stop and free setting original point

  Maximum speed of 500mm/s

  Cutting speed and cutting pressure with memorial storage

  Double photoelectric reset and without any collision

  Perfect output and without any saw tooth at high speed

  Using the most advance subdivision circuit and having low noise

  Using switching power supply and its operation won't be influenced by voltage change

  Circuit uses low power consumption and doesn’t need fan for  heat radiation so as to ensure long and reliable operation
